Telescopic Loader CASER T15D

1.5 Ton Telescopic Loader

CASER T15D Telescopic Loader

Overall Dimensions	Rated Load	1500kg
	Overall Weight	4000kg
	Bucket capacity	0.6cbm
	Bucket width	1860mm
	L x W x H	503218602550mm
	Dumping Height:	2480-3150mm

	Max Tractive Force	36 kn
	Wheelbase	2005mm
	Track Base	1480mm
Standard Engine	Make & Model:	Yunnei 27
	Engine type:	Water-cooled, 4 Cylinder Diesel Engine
	Rated Power:	42Kw @2400rpm
Engine Option #1	Make & Model:	Kohler KDI1903TCR
	Engine type:	3 Cylinder Turbo Diesel 1.9LEngine
	Rated Power:	42kw(56HP)
Transmission system	Type:			Full Hydraulic Power Shift
	Gear Numbers:			2 Forward; 2 Reverse
	Transmission Oil Pressure:			1.2 ~1.5MPa
	Rated input speed:			2500 (rpm)
Operating Specifications	Drive Means:		4-wheel drive
	Steering System		Articulated Frame with hydraulic power steering
	Min Turning Radius:		4500mm
	Time of raise:		4.8sec.
	Hydraulic cycle time:		9.5Second.
Brake System	Service Brake:	Hydraulic Disk Brakes
	Parking Brake:	Hand operated
Tire Size	23.5/70-16
